Magnetek DSD 412 - Page 10

QUICK REFERENCE FOR SET-UP PARAMETERS
10
FNCT.# DESCRIPTION UNIT RANGE DEFAULT
SITE
SETTING
SITE
SETTING
121
SPEED ERROR
THRESHOLD
% 0.0 - 15.0 2.0
130 ARB MODE NUM 0 - 2 0 (OFF)
131 ARB BANDWIDTH RAD 1.0 - 15.0 6.0
132 ARB DAMPING -
0.01 -
20.00
2.00
133
ARB SPD
THRESHOLD
% 0.0 - 10.0 0.0
150 BINARY SELECT ON LOGIC 0 - 1 1=ON
151 PRESET SPEED #1 -
0.0 -
1900.0
0.0
152 PRESET SPEED #2 -
0.0 -
1900.0
0.0
153 PRESET SPEED #3 -
0.0 -
1900.0
0.0
154 PRESET SPEED #4 -
0.0 -
1900.0
0.0
155 PRESET SPEED #5 -
0.0 -
1900.0
0.0
156 PRESET SPEED #6 -
0.0 -
1900.0
0.0
157 PRESET SPEED #7 -
0.0 -
1900.0
0.0
170 ACCEL #1 TIME SEC
0.50 -
15.00
5.00
171 ACCEL #2 TIME SEC
0.50 -
15.00
5.00
172 DECEL #1 TIME SEC
0.50 -
15.00
5.00
173 DECEL #2 TIME SEC
0.50 -
15.00
5.00
174 ACCEL #1 % S %
0.1 -
100.0
25.0
175 ACCEL #2 % S %
0.1 -
100.0
25.0
176 DECEL #1 % S %
0.1 -
100.0
25.0
177 DECEL #2 % S %
0.1 -
100.0
25.0
