Magnetek DSD 412 - Page 9

QUICK REFERENCE FOR SET-UP PARAMETERS
9
FNCT.# DESCRIPTION UNIT RANGE DEFAULT
SITE
SETTING
SITE
SETTING
92 BRAKE AUTO STOP ON LOGIC 0 - 1 0=OFF
93 ANALOG OUT 0 BIAS - -1 - +1 0.0
94 ANALOG OUT 1 BIAS - -1 - +1 0.0
95 ANALOG OUT 0 SELECT
TB1(45)
NUM 0 - 8 1
96 ANALOG OUT 1 SELECT
TB1(46)
NUM 0 - 8 3
97 ANALOG OUT 0 MULT - 00.10 -
10.00
0.80
98 ANALOG OUT 1 MULT - 00.10 -
10.00
0.80
99 SPEED ERROR TRIP
TIME
SEC 0.20 - 5.00 5.00
100 SPEED ERROR TRIP
LEVEL
% 0.0 - 100.0 100.0
101 AUTO FAULT RESET ON LOGIC 0 - 1 0=OFF
102 3S LOOP FLT LOGIC 0 - 1 0=OFF
104 SERIAL GAIN SWITCH LOGIC 0 - 1 0=OFF
105 GAIN SWITCH SPEED PU 0.00 - 1.10 1.10
107 TACH RATE GAIN % 0.0 - 30.0 0.0
110 REFERENCE MODE
SELECT
NUM 1 – 4 2
111 ARCH TRAV DISABLE LOGIC 0 - 1 1=ON
112 FEEDBACK SELECT NUM 0 - 1 1 =
ENCODER
113 ARM VOLTS @ MAX
SPEED
VDC 650 - 0 100
114 PRE-TORQUE ENABLE LOGIC 0 - 1 0=OFF
115 RNUP RNDN ENABLE LOGIC 0 - 1 0=OFF
116 DECEL RATE LATCH LOGIC 0 - 1 0=OFF
120 SPEED ERROR DETECT
TIME
SEC 0.0 - 5.0 0.5
