Magnetek DSD 412 - Page 8

QUICK REFERENCE FOR SET-UP PARAMETERS
8
FNCT.# DESCRIPTION UNIT RANGE DEFAULT
SITE
SETTING
SITE
SETTING
42 STIFFNESS - 0.2 - 9.9 1.0
49 WEAK FIELD CURRENT ADC 0.2 - 40.0 40.0
50 FULL FIELD CURRENT ADC 0.20 -
40.00
1.90
51 MOTOR FIELD L/R SEC 0.10 -
10.00
0.54
52 RTD. FIELD VOLTS DC VDC 50 - 525 240
53 STANDBY FIELD AMPS % 10 - 100 25
54 FIELD RESPONSE RAD 1.0 - 10.0 5.0
55 FIELD CONTROL AC
SOURCE VOLTS
VAC 0 - 525 0
63 U/D PICK-UP % 0.01 -
100.0
0.10
64 LOW SPEED
THRESHOLD
% 0.1 - 100.0 2.0
80 OVER SPEED TEST LOGIC 0 - 1 0=OFF
81 OVER SPEED MULT - 1.00 - 1.50 1.00
82 REFERENCE MULT - 0.500 -
2.000
1.000
83 MOTOR OVERLD TIME SEC 2.0 - 500.0 48.0
84 MOTOR OVERLD LEVEL PU 0.5 - 2 1.15
85 I DECAY RAMP SEC 0.01 - 2.50 0.20
86 ANALOG SPD REF
ZERO
PU -0.02 - 0.02 0.0000
87 PRE-TORQUE MULT - 0.25 - 2.00 1.00
88 DSPR DELAY TIME MIN 0 - 60 0 (OFF)
89 BRAKE PICK TIMER SEC 0.5 - 5.0 1.0
90 BRAKE DROP TIMER SEC 0.5 - 5.0 1.5
91 MUST STOP TIMER SEC 0.1 - 5.0 2.0
