QUICK REFERENCE FOR SET-UP PARAMETERS
7
FNCT.# DESCRIPTION UNIT RANGE DEFAULT
SITE
SETTING
SITE
SETTING
1 CURRENT LIMIT. % 0 - 300 250
2 USE SELF- TUNE
VALUES
LOGIC 0 - 1 0=OFF
3 RTD. ARMATURE AMPS ADC 2.0 -
1250.0
50.0
4 ARMATURE OHMS OHMS 0.001 -
5.000
0.100
6 ARMATURE
INDUCTANCE
HNY 0.0010 -
1.000
0.0100
7 RTD. ARMATURE VOLTS VDC 150 - 550 240
8 I REG CROSSOVER RAD 100 - 1000 500
9 NOMINAL AC INPUT VAC 150 - 525 230
10 ENCODER PPR P/R 600 -
19999
1024
11 RATED MOTOR RPM RPM 50.0 -
1999.0
1150.0
12 OVERSPEED % % 0.0 - 150.0 110.0
14 V SENSE % % 0.0 - 100.0 25.0
15 T SENSE % % 0.0 - 100.0 5.0
16 ENCDR / MTR RATIO - 1.000 -
19.000
1.000
17 RATED CAR SPEED - 1.0 -
1900.0
400.0
21 EXT ACCEL LIMIT n/S^2 2.00 -
10.00
4.20
22 ERROR LIST RESET LOGIC 0 - 1 0=OFF
32 FULL FIELD DETECT % 30 - 90 80
38
ARM VLT RESPONSE
RAD 1.0 - 4.0 2.0
39 HI SPEED BANDWIDTH RAD 1 - 15 6.0
40 LO SPEED BANDWIDTH RAD 1 - 15 6.0
41 PER-UNIT INERTIA SEC 0.10 - 9.99 2.00
