2.5.6 Measured Value Menu
(In the charts that follow, this symbol, >, refers
to .)
The Measured Value menu is used to display
current values being measured by the Sentinel II
(refer to page 15 for the overall menu layout).
Follow this step-by-step procedure to use this
menu. It is assumed that you are starting from
the RUN mode.
Current Menu Location Display Action Comments
Run
Magnetrol Int’l
Normal operation This is the RUN MODE
x.x level units
Run/Measured Values
Measured Values
Access “Measured Values” menu
> to select
Run/Measured Values/ Level
Display the process level
Level units is the unit of measure selected
Level x.x level units under SYSTEM CONFIG.
Run/Measured Values/ Loop
Display the loop current
If the 4–20 mA output has not been
Loop x.x mA programmed, this display will be 4.0 mA.
Run/Measured Values/ Previous menu
Press ENT to move up one level in the program
to Measured Values; or press DEL twice to
Previous Menu > to select
return to the RUN MODE.
Run
Magnetrol Int’l
This is the RUN mode.
level/level units
2.5.7 System Configuration Menu
This System Configuration menu is used to
select the measurement units and to calibrate
the probe for a particular application. Follow this
step-by-step procedure to use this menu. It is
assumed that you are starting from the RUN
mode.
Current Menu Location Display Action Comments
Run
Magnetrol Intl
Normal operation This is the RUN MODE
x.x level units
Run/System Config
Run/System Config/
Access the System Config menu
Use the arrow keys to scroll down until the
>to select display reads “System Config”.
Run/System Config/ Level Units Select the unit of measure for Use the arrow keys to select your option.
Level Units calibration and display.
The “Enter Password” display will not appear
Run/System Config/
Enter password Accept the data entered
if you have entered the password anywhere
Level units else in the general program menu. Use the
numeric keys to type in your password.
Run/System Config/ Probe Calibrate
Access the “Probe Calibrate” Read the following section before continuing.
Probe Calibrate >to select
NOTE: A minimum level change (2% of span) is
required; however, a greater differential will
improve accuracy. Two calibration points will
be entered: Cal Pt. #1 (LO) is the lower point;
Cal Pt. #2 (HI) is the upper point. They may
be entered in any order.
If it is easier to raise the level in your vessel,
set “Cal Pt. #1 (LO)” first; raise the level a
minimum of 2%, then set Cal Pt.
#2 (HI)”. If it is easier to lower the level in your vessel,
then set “Cal Pt. #2 (HI)” first; lower the level a mini-
mum of 2%, then set “Cal Pt. #1 (LO)”.
These calibration points do not have to correspond
with the 4–20 mA output settings or any discrete out-
put set point; they are two arbitrary points along the
length of the probe.
To Next Page
