50-604 Kotron Model 804 Sentinel II RF Level Transmitter
24
3.3 Specifications
3.3.1 Electrical
P
ower supply 120 VAC, 50/60 Hz (+10%, -15%)
240 VAC, 50/60 Hz (+10%, -15%)
24 VDC, (±10%)
P
ower consumption 15 VA nominal
Supply voltage effect Less than 1 pF over full range
Ambient temperature range -40° to +160° F (-40° to +71° C)
H
umidity 99% non-condensing (electronics)
Accuracy Better than ±1.0%
Repeatability ±0.1%
Linearity ±0.5%
Temperature effect ±0.01%/° F ±0.018%/° C)
Operator interface Data entry 16-button keypad
Display 2-line × 16-character LCD display
Continuous output Signal Active 4–20 mA (isolated reversible max. 1000 ohms loop resistance)
Passive 4–20 mA (isolated reversible max. 1000 ohms loop resistance)
Dependent on power supply)
Range 5 pF minimum; 50,000 pF maximum
Damping 0–90 seconds
Discrete output Set point range 0–50,000 pF
Adjustable differential range 0.5 pF minimum
50,000 pF maximum
Time delay 0–90 seconds level rising, level falling, both
Relay output AC 10 amp @ 120/240 VAC resistive
DC 10 amp @ 30 VDC resistive
0.5 amp @ 125 VDC resistive
Maximum remote cable length Standard: 2500 feet (762 m)
Intrinsically safe: 800 feet (240 m)
