Magstim Rapid²
Operating Manual
© The Magstim Company Limited 13 MOP03-EN-03
3.2.2.1 UI Cable* (1)
The UI cable connects the Rapid² UI to the Rapid² mainframe.
3.2.2.2 Mains Power Switch* (2)
The Power switch allows the power supplying the unit to be switched on (labelled I) or off (labelled O).
3.2.2.3 Fuse Access and Voltage Selector* (3)
Access for fuse replacement and changing the voltage selector setting. See section 5.3 for further
details.
3.2.2.4 Power Entry Module* (4)
Power input port on the Rapid² mainframe and Plus¹ module.
3.2.2.5 Link Lead* (5)
The 10A link lead provides powers to the Plus¹ from the PSU and to the mainframe from the Plus¹.
3.2.2.6 Plus¹ Mains Power Switch* (6)
The Power switch allows the power supplying the Plus¹ module unit to be switched on (labelled I) or
off (labelled O).
3.2.2.7 Plus¹ HV Power Output Socket* (7)
This connector is the HV output on the Plus¹ which interconnects the high voltage power between the
mainframe and the Plus ¹ module.
Note: High voltage can be present on this connector.
3.2.2.8 HV Cable* (8)
The HV cable is used to interconnect high voltage power between the mainframe, Plus¹ and the PSU.
3.2.2.9 Isolated Trigger Port* (9)
This 26 way D-Type connector is situated on the rear of the UI and has three rows of pins. It provides
trigger input and output signals. (see Appendix B).
