3.2.2.10 Foot Switch Pneumatic Socket* (10)
This socket is used to connect the pneumatic foot switch to the Magstim Rapid² system. The foot
switch can be used to trigger the instrument when one of the trigger buttons located on the coil is also
pressed. The instrument will continuously charge and discharge if the trigger buttons are pressed and
held.
3.2.2.11 Cooling Fan Outlet (11)
With the Magstim Rapid² system turned on, air is drawn through slots at the bottom of the instrument
and expelled through the fan outlet. There should be no obstructions placed closer than 50mm to the
fan outlet.
3.2.2.12 HV Power Entry Socket (12)
The HV cable is connected to this connector to interconnect the high voltage power between the
mainframe and the PSU.
Note: High voltage can be present on this connector.
3.2.2.13 Earth Strap (13)
The Rapid
2
system must only be used when fitted with the supplied earth straps, this is to maintain the
system’s compliance with EN 60601-1-2 regarding Electro-Magnetic emissions. The strap is fitted
between the stimulator and the Plus¹ unit and between the Plus¹ unit and the PSU.
3.2.2.14 Plus¹ HV Power Input Socket* (7)
This connector is the HV input on the Plus¹ which interconnects the high voltage power between the
PSU and the Plus ¹ module.
Note: High voltage can be present on this connector.
3.2.2.15 Mains input to PSU and Plus¹* (15)
Mains input port on the PSU and Plus¹ module.
