5.The hose A is connected as shown in the fi gure below.
AUX. VALVE ASSEMBLY
AUX. VALVE ASSEMBLY
COUPLING ASSEMBLY
COUPLING ASSEMBLY
HOSE A
HOSE A
INSTALLING REAR WHEEL R.H.
1. Jack up the R.H. rear axle and install the R.H. rear wheels with six bolts (M14x30mm),and
six washers to the axle hub.
Tighten the bolts to the following torque. 109-123Lbfft (147-167Nm)
WASHERS
WASHERS
BOLTS
BOLTS
AXLE HUB
AXLE HUB
REAL AXLE
REAL AXLE
JACK
JACK
