ANALOG INSTRUMENT PANEL
17
OPERATING CONTROLS :
Analog Speedo Meter displays the various aspects as described below :
It is necessary to switch 'ON' the ignition to view the various functions.
1) Speedometer : Indicates driving speed (in km/ h)
2) Odometer : Indicates accumulated distance covered (in km)
3) Fuel meter : Centuro fuel tank capac
4) Neutral Indicator : Glows when gear is only in neutral.
5) Turn signal indicator: Flashes when turn signal button is operated.
6) High beam indicator : Indicates that headlight is on high-beam.
ity is approx. 12.7 litres , for fuel
indication there is ‘F’ mark for full indication ‘E’ mark for
empty indication. Fuel indication displayed in the
speedometer is only an indicative reading.
Refill indication - when needle enter ‘red’ band. It is the
indication to the rider to refill the tank as soon as possible.
1
2
3
N
5
4
6
