Mahindra e Max 25 HSTs - IMPLEMENT ATTACHMENT ADJUSTMENTS; MOUNTING IMPLEMENT

► ADJUSTMENT OF THE CHECK CHAIN
To adjust the check chain turn the turnbuckle to lengthen or shorten the chain and tighten the lock nut
when the correct adjustment is achieved.
►
ADJUSTMENT OF THE LIFT ROD
Check chain
Turn buckle
Fixing Nut
►
ADJUSTMENT
OF
THE
LIFT
ROD
Adjust the length of the lift rod by screwing the Adjusting
Handle (Turnbuckle) in or Adjust the length of the lift rod
as necessary to set the implement in its working position parallel
to the ground.
Lift Rod
Lift
Rod
Ad
j
ustin
g
Handle
41
jg
Lower Link
