► CHANGING OIL IN THE FRONT AXLE
1. Drain the oil from the center diff plug and the drain plug in each drive.
2. Replace and tighten all drain plugs.
3. Remove the Fill/Lever plugs from each final drive to vent air from the final drives.
4. Remove the dip stick from the filter hole and fill with front axle oil capacity to 3.2ℓ (0.85 US gal)
and allow time for the oil to drain into the final drives.
5. Check the oil level with the dipstick and replace the Fill/Lever plugs on both final drives and tighten.
Fill/Level Plug
Some operators have found that when they fill up with the correct amount of oil ,the
level on the dipstick is too high due to the fact that it takes a while for the
oil to run into the final drives.
Opening the Vent plugs helps to speed this up.
Important
► CLEANING AND CHANGING FILTERS
► ENGINE OIL FILTER
Using a filter wrench turn the filter
counterclockwise to remove it.
Lightly smear the rubber seal on the new
filter with oil to ensure, turn it clockwise
until the seal contacts the base and then turn it
another 2/3 turn to tighten it.
58
Engine Oil Filter
Engine Oil Gauge
