Mahindra Maxximo Mini Van Vx 2012 - Egr Actuator Connector

Diagnostic Manual MAN-00183
MAXXIMO MINIVAN VX June 2012/Rev 1
The reproduction, translation, transmission, in part of or whole of the present document are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any
person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution. © 2012 Mahindra &
Mahindra Ltd.
98
EGR ACTUATOR CONNECTOR
Connector
Pin Circuit
EGR ACTUATOR 2 EGR POWER SUPPLY
1 EGR GROUND (ECU)
1
2
E 1
