26.2 Vehicle Specifications
Dimensions and Capacities
Wheelbase
96" (2.44 m)
Dry Weight 2988 lbs. (1355 kg)
Length
148" (3.76 m)
Width
60" - 62" (1.57 m)
Height
75" (1.91 m)
Ground Clearance
9" (22.9 cm)
Fuel Capacity 16 gal. (60.6 l)
Turning Radius
20'
Vehicle Payload Capacity 1525 lbs. (692 kg)
Towing Capacity
3500 lbs. (1588 kg)
Engine
Type
Turbo Diesel
Cylinders 4 - 4 Stroke Compression Ignition
Displacement
2.7L / 166.7 Cu. In.
Bore and Stroke
3.5" x 4.33" (88.9 x 110 mm)
Power 55 HP @ 2300
Torque
144 ft. lbs. @ 1400 rpm
Compression Ratio 18.7
Cooling System Liquid
