Mahindra USA, Inc. All Rights Reserved.
21-1
21 Lifting and Supporting
Place the ROXOR on a flat, non-slippery surface. For hydraulic jack
lifting, place the hydraulic jack under the center of the axle only.
Once lifted, support the ROXOR with suitable jack stands
positioned under the right and left frame rails. If lifting just the
front, or just the back, be sure to block the opposite wheels using
rocks, logs or wheel chocks.
For hoist lifting, only use the two front locations and the two rear
locations shown here.
Front Lifting Location
Rear Lifting Location
Verify the unit is stable on the hoist before raising all the way up
and going underneath it to help prevent an accident resulting in
severe injury or death.
