Mahindra USA, Inc. All Rights Reserved.
23-11
23.14 Replace Engine Air Filter
Service the air filter more frequently if the ROXOR is operated in
dusty conditions. Refer to section 22.1 Severe Dusty Conditions.
Monitor the air filter indicator with engine running only, if the red
indicator is visible the filter should be replaced. (Refer to the below
image)
1. Verify the engine is off and parking brake set.
2. Unlatch and lift the hood, then place prop rod.
3. Remove the air filter housing clamp mounting bolt using a 13
mm socket.
4. Swing the air filter housing clamp up and out of the way.
5. Separate the lower air filter housing from the upper air filter
housing.
6. Gently remove the air filter by pulling straight out. (Refer to
the below image)
Operating a turbo diesel engine with a soiled or damaged air
filter can result in engine damage. Do not attempt to wash
the filter. Always replace a soiled or damaged filter with a
new filter.
7. Clean any dirt or deposits from the inside of the air cleaner
housings.
8. Install the new filter into the lower air filter housing, then
align arrows on upper and lower housings on re-assembly.
9. Reinstall the air filter housing into cradle and swing clamp
into position.
10. Position the air filter housing and tighten the mounting bolt.
Maintenance Procedures
