© Copyright Mahindra and Mahindra Ltd. 112020
9-23
Hardtop assembly must be removed and refitted only at
Mahindra Authorised dealer end.
Mind your head for injury on account of sharp edges of HMSL
body while maneuvering near tailgate with roof top glass open
condition.
99..2211 CCoonnvveerrttiibbllee SSoofftt TToopp FFoolldd aanndd UUnnffoolldd
Open the swing gate and remove the convertible soft top rear
sliding belt rail RH and LH from tailgate bar locking.
Unzipp the convertible soft top rear window as shown in the image.
Unlock the LH and RH rear quarter window Hook.
Quarter Window RH
Quarter Window LH
FFEEAATTUURREESS AANNDD CCOONNTTRROOLL
