1111..22 DDrriivviinngg aanndd OOppeerraattiioonn
• RPAS is an aiding system. Under no circumstances
mahindra will accept any responsibility or can be held liable
for any direct or indirect, incidental or consequential damage
caused by this system
• System will not sense pot holes, trenches or drainages
which are below the ground level
• Applying paint over the sensor will affect the performance of
the system
AAccttiivvaattiioonn && DDee--aaccttiivvaattiioonn ooff RRPPAASS
• The vehicle should be in IIGGNN OONN state to activate the reverse
parking assistance system
• RPAS will be activated automatically when reverse gear is
engaged and deactivate when reverse gear is disengaged
• When the obstacles come in the sensing range, the systems
starts giving the indication based on the distance and direction
of the obstacles as defined in the detecting zones. The closer the
obstacles, more display bars illuminate & frequency of beeps
increases.
1111..33 RRPPAASS IInnffoorrmmaattiioonn oonn IInnssttrruummeenntt CClluusstteerr
RPAS display on the instrument cluster gives the following
information:
• Left zone indicates obstacle on left side
• Right zone indicates obstacle on right side
60 cm
RREEVVEERRSSEE PPAARRKKIINNGG AASSSSIISSTT SSYYSSTTEEMM ((RRPPAASS))
