© Copyright Mahindra and Mahindra Ltd. 112020
2-5
22..33 BBuullbb SSppeecciiffiiccaattiioonn
LLaammpp BBuullbb WWaattttaaggee
Head Lamp 12V H4 55/60W
Park lamp
12V W5W
Front Turn lamp
12V PY21W
Front Fog lamp
12V H16-19W
Side Turn Signal lamp
12V W5W
DRL/Position lamp
LED: DRL 4.86W, For Position
0.54W
Tail / Stop lamp
LED: Stop 6.8W, Rear Position
0.9W
Rear Turn lamp
12V WY16W
Front Position Lamp
12V W5W
Reverse lamp
12V W16W
Registration Plate lamp
LED: 0.3W
22..44 FFuusseess aanndd RReellaayyss
A fuse is the most common electric protection device. The fuse is
placed in an electrical circuit, so that when current flow exceeds
the rating of the circuit/fuse, it blows off. The element in the fuse
melts, opening the circuit and preventing other components of the
circuit from being damaged by the over current. The size of the
metal fuse element determines the rating. Once a fuse blows off, it
must be replaced with a new one of the same rating.
Switch the ignition and all electrical equipment OFF before touching
or attempting to change a fuse.
Replacement fuse must be with the same rating as the one you
have removed.
You can identify a blown fuse by a break in the filament. All
fuses except high current fuses are press fit.
Never touch fuses with bare hands. Always use the fuse puller
to remove and refit the fuses.
Be careful while removing the relay, to avoid damage to relay
terminal — do not shake or apply excessive force .
