22..44..22 EEnnggiinnee CCoommppaarrttmmeenntt FFuussee BBooxx The engine compartment fuse box is located adjacent to the
vehicle’s battery.
Follow the below steps to remove the fuse cover;
• To open the fuse box cover, press the lock and push the cover
back and lift it.
Fuse puller is available in the fuse box cover.
