Mahr GmbH, MarSurf PS 10
6.1 Checking the integrated standard
To determine the Rz value of the integrated
standard:
1. Position a suitable roughness measuring
instru ment
9
in such a way that the probe
is on top of the standard and a traversing
length of 5.6 mm (0.220 in) can be meas-
ured (see figure 3).
2. Set the traversing length Lt = 5.6 mm
(0.220 in) on the measuring instrument.
3. Perform one or several measurements and
read off the measured Rz value in each case.
4. Average the measured Rz values.
5. Enter the calculated Rz value as the Rz
nominal value during the next calibration
with the MarSurf PS 10.
9 e.g. MarSurf SD 26 drive unit with BFW-250 skidless
probe and MarSurf M 400 or MarSurf XR 1 evaluation
instrument
Transport / shipment
Caution:
The drive unit and probe can be dam-
aged during transport or shipping.
The following instructions must be ob-
served when transporting or shipping
the instrument. Otherwise, all warranty
claims will be void!
When transporting internally in the carry case:
1. Place the red shipping clamp from below
on the vee-block holder (9) (see information
sheet 3763316).
2. Switch off the MarSurf PS 10 and stow it in
the carry case.
When shipping:
1. Switch off the MarSurf PS 10.
2. Remove the drive unit from the MarSurf
PS 10 (see µ in Section 4).
3. Place the red shipping clamp from below
on the vee-block holder (9) (see information
sheet 3763316).
4. Stow the drive unit in the dedicated com-
partment of the corresponding shipping
box.
5. Pack the MarSurf PS 10 (in its carry case)
and the rest of the accessories into the ship-
ping box.
