Maico easyTymp User Manual

Operation Manual easyTymp
8111254 Rev. 9
33
17/01/2018
Each ear tip should only be used once. For more detailed
information see section 3.3.4.
Figure 42
In order to remove the ear tip, grasp the ear tip at the base
using the eartip removal tool and pull it smoothly straight
off the probe tube (Figure 42).
NOTE: If the probe tip becomes dirty or clogged, it must
be cleaned (see section 3.3.3) or replaced
5.2.5 easyTymp Plus and Pro Version: Placing and Using the Contra Probe
Figure 43
A clip is located on the back of the Contra Probe which
can be attached to the patient’s clothing (Figure 43). For
most patients it is easiest to clip the Contra Probe to the
patient. When a child is being held by a parent, clip the
Contra Probe to the parent’s clothing.
Figure 44
Press the button on the Contra Probe to start or
stop/pause the current measurement or switch between
right and left when the probe is not inserted to the ear
(Figure 44).
5.2.6 easyTymp Plus and Pro Version: Placement of Contralateral Earphones
Multiple transducers are available for purchase to perform Contralateral measurements.
Figure 45
If the CIR55 or insert phone is used, place the proper
eartip on the insert before inserting the phone into the
non test-ear (Figure 45).
Figure 46
If the DD45C is used, place the head band over the
patient’s head. The audiometric headphone is placed
over the non test-ear (or Contralateral Reflex ear)
(Figure 46).
WARNING
