Maico easyTymp User Manual

Operation Manual easyTymp
8111254 Rev. 9
48
17/01/2018
DEVICE SPECIFICATIONS
Environment
Conditions:
Operation
+15 °C to +35 °C / +59 °F to +95 °F
Humidity: 30 % to 90 %, non-condensing
Air pressure 98 kPa to 104 kPa
1
Maximum altitude: 2000 m / 6561 ft
above sea level
Storage
0 °C to +50 °C / +32 °F to +122 °F
Humidity: 10 % … 95 %, non-condensing
Transport
-20 °C to +50 °C / -4 °F to +122 °F
Humidity: 10 % to 95 %, non-condensing
Power, easyTymp
Fuses:
3 A (5 V)
Battery Type
NP120 Li-Ion
3.7 V 1700 mAh
Dimension and weight:
Dimension
80 mm x 300 mm x 70 mm
3.15” x 11.81” x 2.76”
Weight
427 g / 1 lb
Display:
Display size:
2.2” diagonal
Resolution:
240 x 320
PC connection:
USB:
Input/output for computer
communication.
Memory:
Stores test results for up to 499 patients.
The easyTymp hand held unit is delivered
with a 8 GB memory card
Mode of operation
Continuous
Dimensions Probe
34 mm
Dimensions External
Probe:
350 mm (cable)
Dimensions Contra
Probe:
1400 mm (cable)
Warm-up time:
less than 10 minutes
__________
1
Environment conditions during operating according IEC 60645-1
NOTE: Reference equivalent threshold sound pressure levels may differ significantly with
ambient pressures outside the above range. Therefore recalibration around the normal
ambient pressure at the site of the user should be undertaken in those circumstances
where the calibration site and the user site do not share similar ambient conditions.
