Maico easyTymp User Manual

Operation Manual easyTymp
8111254 Rev. 9
53
17/01/2018
CRADLE
Power supply,
UE24WCP-240100SPA
Consumption:
0.6 A
Mains voltages
and fuses:
100 - 240 VAC, 50 - 60 Hz
Power
Fuses:
24V/3 A
Dimensions and Weight
Dimensions
Max. 280 mm x 250 mm x 120 mm
11.02” x 9.84” x 4.71”
Weight
980 g / 2.16 lbs
PRINTER
Print mode
Thermal line dot print
Printing width: 48 mm (1.9 in)
Resolution: 8 dots/mm (203 dots per in (dpi))
Dots per line: 384 dots
Thermal paper
Paper width = 56mm +/- 1 mm (2.2 in +/- 0.04 in) max. 40 mm
(1.6 in) diameter
Battery pack
2-cell Li-Ion battery pack 7.4 V-1500 mAh
Power supply /
charger
12 V/1 A UE15WCP1-120125SPA
Maximum current consumption 0.5 A (see also Figure 74)
Size
02 mm x 75 mm x 45 mm
(4.02 in x 2.95 in x 1.77 in)
Weight
Weight: 205 g including battery, without paper
Environment
Conditions:
Operational temperature range: -10 °C to +50 °C (+14 °F to +122 °F)
Operational humidity range: 20 % to 85 %
Storage temperature range: -20 °C to +70 °C (-4 °F to +158 °F)
Figure 74
