13 Technical data
68
13 Technical data
13.1 Technical data for PP 45
External diameter DN 160
Length of
wall sleeve
PP 45 RHK:500mm
PP45RHL:800 mm
Wall thickness min. 265mm
max. 490 or 790mm
Air filter, outside Filter class ISO16890
ISO coarse 45%(G3)
Air filter, inside Filter class ISO16890
ISO coarse 30%(G2)
Air volume/unit 42 m³/h
Degree of protection IP 00
Sound pressure level:
at distance of 1 m,
free-field conditions
(ventilation levels 1 to
5)
23 / 28 / 33 / 37 / 40
dB(A)
Rated voltage PP 45 O, PP 45 K: 12V
PP 45 RC: 230 V
Power frequency 50/60 Hz
Volumetric flows for
ventilation levels 1, 2,
3, 4, 5
15 / 20 / 30 / 36 / 42 m³/
h
Power consumption 1.2 / 1.7 / 2.1 / 2.8 / 3.5
W
Permissible ducting
lengths with wired
connection
From star point, max.
25m per ventilation unit
Weight of complete
slide-in module
3 kg
Radio components:
Frequency range (in
acc. with
EN300220-1)
868.35 MHz
Radio receiver with in-
ternal antenna
Do not mount on the
wall side of the trans-
mitter
“Wireless” operating
distances in the build-
ing are dependent on
the building materials
used:
up to:
DS 45 RC → PP 45 RC 30 m
PP 45 EO → PP 45 RC 30 m
PP 45 RC → PP 45 RC 30 m
With PP 45 RC as
amplifier
40 m
For more technical data → rating plate.
13.2 Technical data for PPB 30
External diameter DN 160
Length of
wall sleeve
PP 45 RHK: 500mm
PP 45 RHL: 800 mm
Wall thickness 320 – 790mm
Air filter Filter class ISO16890
ISO coarse 45% (G3) 2
items
Air volume/unit 26 m³/h
Degree of protection IPX4
Sound pressure level:
at distance of 1m,
free-field conditions
(ventilation levels 1 -
5)
18 / 32 / 41 / 45 / 49
dB(A)
Rated voltage PPB 30 O, PPB 30 K:
12V
PPB 30 RC: 230 V
Power frequency 50/60 Hz
Volumetric flow in
heat recovery mode,
ventilation levels
1to5
5 / 12 / 18 / 22 / 26 m³/h
Volumetric flow in ex-
haust air mode (no
heat recovery unit)
45 m³/h
Power consumption 1.7 / 2.5 / 3.4 / 4.4 / 5.3
W
Degree of heat provi-
sion
73.3% (level3)
SPI 0.19 W / (m³/h)
SEC value A (-39,71 kWh / (m²*a))
Permissible ducting
lengths with wired
connection
From star point, max.
25m per ventilation unit
Weight of slide-in
module, cpl.
3.6 kg
Radio components:
Frequency range (in
acc. with
EN300220-1)
868.35 MHz
Radio receiver with in-
ternal antenna
Do not mount on the
wall side of the trans-
mitter
