MP1900X Series Router Installation Manual Router Introduction
copyright2019 Maipu, all rights reserved
1-5
Figure 1-5 Air passage of MP1900X series router
 Keep the air passage of the route unblocked during the operation.
 Avoid placing the device with left outlet adjacently above and below the
router.
1.5 Power Module of MP1900X Series Router
The back panel of MP1900X series router provides one power input.
MP1900X-12-AC and MP1900X-22-AC are fixed with one power. The power
model and function description are as follows:
Table 1-3 Power modules supported by MP1900X
Model Name Remarks
AD30-1S005D
30W ACDC
power
Output 12V system power
