7
5. SYMBOLS AND ANNUNCIATORS
Low pass filtering
Timing symbol
Backlight
bargraph
Continuity
Diode test
Battery status
9
nano (10- ) (capacitance)
6
micro (10- ) (amps, cap)
3
milli (10- ) (volts, amps)
Amps
3
kilo (10 ) (ohms)
Farads (capacitance)
6
mega (10 ) (ohms)
Ohms
Peak Hold
Hz Hertz (frequency)
Volts
Percent (duty ratio)
Relative
Alternating current
Direct current
Degrees Fahrenheit
Degrees Centigrade
Auto Range Timing
Display hold
Minimum
Maximum
Alternating current + Direct current
True RMS
Store
Recall
Auto Range
Resistance low operator indication
Bluetooth
n
µ
m
A
k
F
M
Ω
PEAK
REL
AC
DC
MAX
AUTO
HOLD
AUTO
MIN
AC + DC
⁰F
⁰C
%
Hz
V
TRMS
LOG
VIEW
Function Range Resolution Accuracy
PFC/PSC 0 to 10kA 1A
0 to 50kA 1A
Earth Fault Current (PFC).
Short Circuit Current (PSC).
Determined by accuracy of loop resistance and mains voltage measurements.
RCD (BSEN 61557-6)
RCD Rating 10mA 30mA 100mA 300mA 500mA 650mA 1A
Voltage Range 220V±10% (45Hz to 65Hz)
Accuracy of the Current lΔn, 2*lΔn, 5*lΔn: (0% + 10%)
of the RCD 1/2*lΔn: -10% to 0%
Range of the Timing of 1/2*lΔn: 0mS to 2000mS
the RCD 1*lΔn: 0mS to 300mS
2*lΔn: 0mS to 150mS
5*lΔn: 0mS to 40mS
Resolution of the RCD 0.1ms
Timing
Accuracy of the Timing ±(5%+5)
of the RCD
Accuracy of the Current ±(10%+4)
of the RCD
Function Range Resolution Accuracy
LINE Resistance 0.23 to 9.99Ω 0.01Ω
±(4% of reading + 6
L- N 10.0 to 99.9Ω 0.1Ω
digits)
100 to 999Ω 1Ω
Measuring Current: 8A to 25.0A.
Range of the Voltage Used: 195VAC to 260VAC (50,60Hz).
Function Range Resolution Accuracy
AC 80 to 500V 1V ±(2% of reading + 2 digits)
Frequency 45 to 65Hz 1 Hz ±2Hz
Low Ohm 0.000 to 2.000Ω 0.001Ω ±(1.5% of reading + 30 digits)
2.00 to 20.00Ω 0.01Ω ±(1.5% of reading + 3 digits)
20.0 to 200.0Ω 0.1Ω
200 to 2000Ω 1Ω ±(1.5% of reading+ 5 digits)
Earth 0.00 to 99.99Ω 0.01Ω ±(2% of reading + 30 digits)
100.0 to 999.9Ω 0.1Ω ±(2.5% of reading+ 6 digits)
1000 to 2000Ω 1Ω
Max. Open Circuit Voltage: 5.0V ± 1V DC.
Overload Protection: 250V RMS.
Resistance
Voltage
