Major 4200 - Page 44

40 www.major-equipment.com
STANDARD BLADE SYSTEM - on: 6000, 8000, 12000, 12FT3PL, 17000 & 18000 prior to April 2009
MACHINE MODEL: 6000, 12000, 12FT3PL, 17000 & 18000GR
MACHINE MODEL: 8000
Item Part No Description Qty
1 1/2F 1/2” Nyloc Nut 6
2 DF-BMP BLADE MOUNT 1
3 GM26 BLADE BACK 2
4 M20 M20 NYLOC NUT 2
5 FWM20 M20 FLAT WASHER 4
6 12T-LBB Overlap Blade Bushing 2
7 12T-OLB Overlap Blade 2
8 NTSB10A SWING BLADE (Anti-Clk) 2
9 8SM9/1 Swing Blade (Clockwise) 2
10 M20X60BZP M20x60 BOLT 2
11 12X212FBZP 1/2”x2 1/2” FINE BOLT 4
12 12T-BBS BLADE BACK SPACER 4
Item Part No Description Qty
1 1/2F 1/2” Nyloc Nut 6
2 DF-BMP BLADE MOUNT 1
3 8SM9/2 Blade Back
4 M20 M20 NYLOC NUT 2
5 FWM20 M20 FLAT WASHER 4
6 12T-LBB Overlap Blade Bushing 2
7 12T-OLB Overlap Blade 2
8 NTSB10A SWING BLADE (Anti-Clk) 2
9 8SM9/1 Swing Blade (Clockwise) 2
10 M20X60BZP M20x60 BOLT 2
11 12X212FBZP 1/2”x2 1/2” FINE BOLT 4
12 12T-BBS BLADE BACK SPACER 4
