Time Scales of the Morphagene: Reels
13
Note: The following diagrams all assume nothing is patched into the Play Input so the Morphogene is playing back
continuosly. To hear the entire Splice, turn Gene-Size full counterclockwise. Diagrams not scale. If no microSD Card is
present, then only one Reel may be created and Reel mode cannot be entered.
Reels are stored on the MicroSD card. The Reel Activity Window diplays Reels in the following color order:
The current Reel is loaded on the Morphagene, or a new Reel is created. Starting with an Empty Reel, hold the REC Button and
press the Splice Button to start the recording process.
Maximum Length: 2.9 minutes
Reels can be divided with a maximum of 299 Splice Markers, resulting in a maximum of 300 possible Splices.
The current Splice is indicated by the Splice Activity Window:
Splice Marker 1 Splice Marker 2 Splice Marker 3 Splice Marker 4
<Press>
Splice Marker 1
<Press>
<Hold>
2.
1.
Additional Reels
repeat in this
color order
To Next Page
