BOXER SERIES10-20 KVA INSTALLATION
AG-SD-109 Publishing Date: 13.10.2015 Revision No: 0 Rev. Date:
3.1.3.3 Placing External Batteries
Batteries should be mounted in an environment where the temperature is consistent and even
over the whole battery. Temperature is a major factor directly affecting the battery life and
capacity. In general, battery manufacturers recommend that batteries be used in 20-25 °C.
Furthermore, battery manufacturer companies indicate the performance of batteries according
to the said temperature range. If the temperature exceeds the said range, the life of the battery
will decrease. On the contrary, again if the temperature drops the said range, the capacity of the
battery will seriously decline. Therefore, expected time will not be obtained during back up. As a
result, keep batteries away from heat sources and serious air flows. Pay attention to the said
factors and be careful about and observe the following points in terms of external connections of
the batteries:
Keep batteries away from main heat sources.
Keep batteries away from serious air flows.
Keep batteries away from the humid places. Hereby batteries can be prevented from
terminal oxidations and possible leakage currents.
Please use aR or gR semi-conductor type fuse at the battery rooms and cabinets.
If it is possible, please use breaker switch without fuse for the battery cabinet.
Keep battery cabinets and shelves high above the ground. UPS should be protected
against possible floods or liquid contacts.
