Makita DS4012 Technical Information

P 9/ 12
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-4. Leaf spring
Fig. 9
ASSEMBLING
Assemble two Leaf springs to Handle L as drawn in Fig. 9.
Face the curve tops toward notches of
Motor housing.
Projections
Projections
Note: Be careful not to fall Leaf springs
in Handle L.
notch
Fit the projections of Leaf spring to
the notches of Handle L.
Notches of Motor housing
Handle L
Handle L

Makita DS4012 Specifications

General

Drilling	Yes
Screwdriving	-
Idle speed (max)	600 RPM
Idle speed (min)	0 RPM
Chuck capacity (max)	- mm
Drilling diameter in wood (max)	36 mm
Drilling diameter in steel (max)	13 mm
Amperage	8.5 A
Power source	AC

Weight and Dimensions

Depth	340 mm
Width	83 mm
Height	390 mm
Weight	2800 g
