P 2/ 35
Cutting capacities [Height x Width in mm (")]
Cutting capacities [Height x Width in mm (")]
Miter angle
Bevel angle
0 degree
45 degrees left
92 x 382 (3-5/8 x 15)
107 x 363 (4-1/4 x 14-1/4)
61 x 382 (2-3/8 x 15)
71 x 363 (2-13/16 x 14-1/4)
78 x 325 (3-1/16 x 12-3/4)
80 x 292 (3-1/8 x 11-1/2)
115 x 325 (4-1/2 x 12-3/4)
120 x 292 (4-3/4 x 11-1/2)
115 x 227 (4-1/2 x 8-15/16)
120 x 212 (4-3/4 x 8-3/8)
115 x 197 (4-1/2 x 7-3/4)
120 x 180 (4-3/4 x 7-1/8)
115 x 155 (4-1/2 x 6-1/8)
120 x 140 (4-3/4 x 5-1/2)
61 x 325 (2-3/8 x 12-3/4)with 20 x 38 (13/16 x 1-1/2)
auxiliary wood fence
with 15 x 25 (9/16 x 1)
auxiliary wood fence
with 15 x 25 (9/16 x 1)
auxiliary wood fence
with 15 x 25 (9/16 x 1)
auxiliary wood fence
44 x 382 (1-3/4 x 15)
54 x 363 (2-1/8 x 14-1/4)
45 degrees
left & right
92 x 268 (3-5/8 x 10-1/2)
107 x 255 (4-1/4 x 10)
61 x 268 (2-3/8 x 10-1/2)
71 x 255 (2-13/16 x 10)
44 x 268 (1-3/4 x 10-1/2)
54 x 255 (2-1/8 x 10)
92 x 233 (3-5/8 x 9-1/8)
107 x 220 (4-1/4 x 8-5/8)
45 degrees right0 degree
52 degrees
left & right
92 x 185 (3-5/8 x 7-1/4)
107 x 178 (4-1/4 x 7)
60 degrees right
Capacities of cutting Crown molding and Baseboard (Skirt board)
Crown molding,
45 degree type
203 (8)*2 Diagonal cut*1
Workpiece
Capacity: mm (")
How to cut
320 (12-5/8)Horizontal cut
165 (6-1/2)Vertical cut
416 (16-3/8)*3Horizontal cut
Baseboard
(Skirt board)
European countries
All countries
*1 Diagonal cut is to cut a crown molding that is
held tilted against the guide fence using
Crown molding stopper.
*2 The capacity of crown molding diagonal cut
is the length L shown in the drawing on right.
*3 No need for setting auxiliary wood facing
on the turn base
L
All countries except European countries
Standard equipment
Optional accessories
Note: The standard equipment for the tool shown may vary by country.
Vertical vise ................. 1
TCT saw blade ............ 1
Dust bag assembly ....... 1
Socket wrench 13 ....... 1
Triangular rule ........... 1
Lock-off button ........... 1
TCT saw blades, Holder set, Stand, Horizontal vise, Crown molding stopper set, Dust box set
Holder set ............. 2 (all countries except North America)
Hex wrench .......... 1 (LS1216L only)
Miter angle
Bevel angle
0 degree
45 degrees left
87 x 382 (3-7/16 x 15)
102 x 363 (4 x 14-1/4)
59 x 382 (2-5/16 x 15)
69 x 363 (2-3/4 x 14-1/4)
78 x 290 (3-1/16 x 11-3/8) 115 x 300 (4-1/2 x 11-3/4)
120 x 250 (4-3/4 x 9-7/8)
115 x 202 (4-1/2 x 8)
120 x 172 (4-3/4 x 6-3/4)
115 x 178 (4-1/2 x 7)
120 x 155 (4-3/4 x 6-1/8)
115 x 140 (4-1/2 x 5-1/2)
120 x 122 (4-3/4 x 4-13/16)
61 x 290 (2-3/8 x 11-3/8)with 35 x 60 (1-3/8 x 2-3/8)
auxiliary wood fence
with 30 x 45 (1-3/16 x 1-3/4)
auxiliary wood fence
with 25 x 35 (1 x 1-3/8)
auxiliary wood fence
with 25 x 35 (1 x 1-3/8)
auxiliary wood fence
44 x 382 (1-3/4 x 15)
54 x 363 (2-1/8 x 14-1/4)
45 degrees
left & right
87 x 268 (3-7/16 x 10-1/2)
102 x 255 (4 x 10)
59 x 268 (2-5/16 x 10-1/2)
69 x 255 (2-3/4 x 10)
44 x 268 (1-3/4 x 10-1/2)
54 x 255 (2-1/8 x 10)
87 x 233 (3-7/16 x 9-1/8)
102 x 220 (4 x 8-5/8)
45 degrees right0 degree
52 degrees
left & right
87 x 185 (3-7/16 x 7-1/4)
102 x 178 (4 x 7)
60 degrees right
