Makita LS1216 Technical Information

P 5/ 35
Repair
[2] LUBRICANT (cont.)
Fig. 3
Item No.
Description Portion to lubricate
Lubricant
Amount
a little
Turn base
Spur gear 43
Rack block
Slide plate
Miter lock plate B complete
Portion where Turn base contacts
Hole where Grip 50 contacts
Slide lock plate Long length hole
Linear bearing
box complete
Rod 16
Spring roll ends where Dront arm complete contacts
Blade case complete
Knob 20
Hinge portion
Whole portion
Whole portion
Makita grease
SG No.0
63
63
149
Sleeve 17 Outer periphery where Torsion spring 40 comtacts
150
150
154
210
210
214
Base complete Inside of center rib for receiving axis of Turn base
242
242
248
248
271
271
214
154
154
149
153
63
152
Arm complete
Torsion spring 40
Portion where Blade case complete contacts
157
157
157
Front arm complete
Portion where Front arm complete contacts
153
Stopper pin
152
O ring 7
Grip 50
Rib on the reverse of Turn base
Portion where Rib on the reverse of Turn base contacts
Portion where the reverse of Rack contacts
Racks where Spur gear 43 engages

Makita LS1216 Specifications

General

Blade Diameter	12 inches
Arbor Size	1 inch
Voltage	120V
Power Source	Corded
Type	Sliding Compound Miter Saw
Miter Range	52° L, 60° R
Cutting Capacity (90°)	12 inches
Cutting Capacity (45° Bevel)	8 inches
Amp Motor	15 Amp
