E L E C T R I C A L S T A R T I N G S Y S T E M
3. Starter motor
Use a bridge cable (3) to connect the positive battery terminal (1) to the cable of the starter motor (2), as shown
•
•
To connect, use cables that are compatible with the power draw of the starter motor.
4. Starter relay
Connect the battery to the terminals of the starter relay (4) using bridge cables (1)
Pole (+) of battery Red
Pole (-) of battery White/Red
•
•
•
•
