Malaguti X3M - Troubleshooting Chart

48
5
2
3
4
1
6
7
8
9
PERIODIC MAINTENANCE AND MINOR REPAIR
ENGLISH
The engine doesn’t start. Ask a
MALAGUTI Dealer to check.
Open throttle half-way and start the
engine.
Wipe clean with dry cloth and correct
electrode gap or replace spark plug.
Wet.
Dry.
Remove spark plug
and check electrodes.
Go to ignition check.
There is compression.
No compression.
Ask a
MALAGUTI Dealer to check.
Use kickstarter.
Go to compression check.
Enough fuel.
Little fuel.
Check if there is fuel
in the fuel tank.
Supply fuel.
Engine doesn’t start. Go to compression check.
1. Fuel
2. Compression
3. Ignition
Keep away open flames and do not smoke while checking or working on the fuel system.
TROUBLESHOOTING CHART
Ask a MALAGUTI Dealer to check.
The engine does not start. Ask a
MALAGUTI dealer to check.
Battery is charged
The starter motor is
running fast.
The starter motor is
running slowly.
Recharge the battery and check
the connections.
Use the START
button
4. Battery
