18 MicroCal iTC
200
Washing Module User Guide
Electrical Connections for the Washing Module
Connect the power cord from the power supply to the power receptacle on the rear of the washing
module. Connect the power supply to a main power supply receptacle with a 3-wire protective Earth
ground and a Ground Fault Circuit Interrupter (GFCI).
WARNING
To enhance safety always plug the instrument into a
Ground Fault Circuit Interrupter (GFCI) device.
Washing module power supply unit
WARNING
Electrocution hazard
Multiple power sources. Disconnect all power sources
before servicing.
MicroCal iTC200 Washing Module
