MicroCal iTC
200
Washing Module User Guide 7
Part 1: Bottle Preparation
Note: Turn the MicroCal iTC
200
off and disconnect it from power before proceeding.
1. Remove the four bottles from their packaging. Using
the standard tubing, the bottles will need to be
located within about three feet (1m) of the washing
module.
The bottle with the blue top
(ASY021396) will be used for water.
The bottle with the red top
(ASY021398) will be used for methanol.
The bottle with the white top
(ASY021397) will be used for buffer.
The bottle with the grey top
(ASY021615) will be used for waste.
2. The wast
e bottle assembly includes
two waste lines. Set them aside.
3. Remove the three tygon tubing assemblies
(ASY021608) from the ir packaging and screw them
onto the tops of the red, white and blue bottles.
4. Set the four bottles aside in a safe location near the cell unit.
MicroCal iTC200 Washing Module
