2 - 6
TYRES
Wheel nut tightening torque ; front wheels 34 daNm
Wheel nut tightening torque ; rear wheels 22 daNm
120 AETJ L
SPECIFICATIONS
- Use Indoors and Outdoors
- Capacity 200 Kg including 2 people
- Maximum authorized wind speed 45 Km/h
- Control system Hydro-electric
- Turret rotation 355°
- Working speed 0,6 km/h
- Speed in transport 5 km/h
- Working height 11950 mm
- Height of floor 9950 mm
- Max. offset 6870 mm
- Weight of the access platform
• Unloaded 5050 kg
• In nominal load 5250 kg
- Number of speed 2
- Negotiable slope 30%
- Max. permissible tilt 5% or 3°
LOAD PER WITH MAX. LOAD
CONTACT SURFACE
DIMENSIONS TYPE TYRE UNLADEN + D OFF-CENTRING ON 1 WHEEL
OF 1 WHEEL WITH GROUND
STAMPING
FRONT REAR FRONT / REAR
600 X 190 TYRE 2370 KG 2680 KG 2800 KG - CM
2
- DAN/CM
2
