2 - 7
TYRES
Wheel nut tightening torque ; front wheels 34 daNm
Wheel nut tightening torque ; rear wheels 22 daNm
150 AETJ C
SPECIFICATIONS
- Use Indoors and Outdoors
- Capacity 200 Kg including 2 people
- Maximum authorized wind speed 45 Km/h
- Control system Hydro-electric
- Turret rotation 355°
- Working speed 0,6 km/h
- Speed in transport 5 km/h
- Working height 14990 mm
- Height of floor 12990 mm
- Max. offset 7600 mm
- Weight of the access platform
• Unloaded 6700 kg
• In nominal load 6900 kg
- Number of speed 2
- Negotiable slope 23%
- Max. permissible tilt 5% or 3°
LOAD PER WITH MAX. LOAD
CONTACT SURFACE
DIMENSIONS TYPE
TYRE UNLADEN
+
OFF-CENTRING ON 1 WHEEL
OF 1 WHEEL WITH GROUND
STAMPING
FRONT REAR FRONT / REAR
600 X 190 TYRE
2930 KG 3770 KG 3600 KG - CM
2
- DAN/CM
2
