TYRES
Wheel nut tightening torque ; front wheels 34 daNm
Wheel nut tightening torque ; rear wheels 22 daNm
2 - 8
150 AETJ L
SPECIFICATIONS
- Use Indoors and Outdoors
- Capacity 230 Kg including 2 people
- Maximum authorized wind speed 45 Km/h
- Control system Hydro-electric
- Turret rotation 355°
- Working speed 0,6 km/h
- Speed in transport 5 km/h
- Working height 15280 mm
- Height of floor 13280 mm
- Max. offset 7810 mm
- Weight of the access platform
• Unloaded 5910 kg
• In nominal load 6140 kg
- Number of speed 2
- Negotiable slope 26%
- Max. permissible tilt 5% or 3°
LOAD PER WITH MAX. LOAD
CONTACT SURFACE
DIMENSIONS TYPE TYRE UNLADEN + D OFF-CENTRING ON 1 WHEEL
OF 1 WHEEL WITH GROUND
STAMPING
FRONT REAR FRONT / REAR
600 X 190 TYRE 1240 KG 1715 KG 3600 KG 283 CM
2
12,5 DAN/CM
2
