2 - 21
NB :
INCOHERENCE of OVERLOAD SENSORS,
LOW ARM position and TELESCOPE extension
/ retraction.
This memo is to inform you that the slope and overload LEDs
may, in certain situations, be activated intermittently and the
beeper may sound constantly, for reasons other than excessi-
ve slope position or overloaded basket.
For your safety, the access platform is equipped with two overload
sensors. If only one sensor is activated, the access platform is bloc-
ked, the display (see Ref. 7 on the following pages) displays fault
code "F02004". At the same time :
on the basket console : on the base console :
- Beeper 33* sounds constantly. - LED 3* flashes regularly.
- LED 22* flashes in sets of 5 flashes - LED 4* flashes in sets of 5 flashes
every 2 seconds. every 2 seconds.
For your safety, the access platform is equipped with two sensors for the low arm position and two for telesco-
pe extension / retraction. If only one sensor is activated in either of these functions, the display (see Ref. 7
on the next page) displays fault code "F02005". At the same time :
on the basket console : on the base console :
- Beeper 33* remains silent. - LED 4* flashes in sets of 5 flashes
- LED 22* flashes in sets of 5 flashes every 2 seconds.
every 2 seconds.
If the fault continues to be displayed, immobilise the platform and make the necessary repairs.
Consult your dealer.
* : the above references are the same as those used in the description of these components in the following
pages.
