2 - 23
A- GROUND BACKUP AND MAINTENANCE STATION
1 - EMERGENCY STOP
2 - KEY-OPERATED CONTROL SELECTOR SWITCH AT GROUND LEVEL OR IN THE
BASKET
3 - OVERLOAD LAMP
4 - "MAINTENANCE MACHINE" LAMP
5 - "STATE OF CHARGE OF THE BATTERY" LAMP
6 - "DEAD MAN" BUTTON
7 - BATTERY CHARGE INDICATOR AND THE HORAMETER
8 - PLATFORM ROTATION CONTACTOR
9 - RAISE AND LOWER CONTACTOR OF THE EXTENSION ARM
10 - ROTATION CONTACTOR FOR ROTATED JIB (OPTION 3D)
11 - TELESCOPE OUTPUTS AND INPUTS CONTACTOR
12 - RAISE AND LOWER CONTACTOR OF THE SUPERIOR ARM
13 - RAISE AND LOWER CONTACTOR OF THE INFERIOR ARM
14 - TURRET ROTATION CONTACTOR
15 - INCLINATION CONTACTOR OF THE PLATFORM
16 - BATTERY SWITCH
17 - FLASHING LIGHT (OPTION)
18 - SLOPE SENSOR
19 - SOUND ALARM HORN
20 - BLOCKAGE OF THE TURRET ROTATION
