Manitou 150 AETJ C - Platform Characteristics

2-9
PLATFORM CHARACTERISTICS
FUSES
- Main card (Base control box ) 5A (1 Fig A) and 15 A (2 Fig. A)
- Power (Contactor plate)
- Electric pump (Variable speed drive plate
325 A (3 Fig B)
100 A (4 Fig C)
A
B C
4
3
1
2
