Manitou 150 AETJ C User Manual

3-9
MAINTENANCE TABLE  150 AETJC  150 AETJC 3D 170 AETJL
(1) : COMPULSORY OVERHAUL EVERY 50 HOURS OR 6 MONTHS
This overhaul must necessarily be conducted close to the initial 500-hour period or within the 6 months following putting the
machine into service (on reaching the first term period)
A = REGULATE, C = CHECK, G = GREASE,
N = CLEAN, P = BLEED,
R = REPLACE, V = DRAIN
PAG E
(1)
DAILY OR
5 HOURS
6
MONTHS
OR
50 HOURS
1 YEAR OR
100
HOURS
2 YEARS
OR
200
HOURS
OCCASIONAL
TRANSMISSION
Rear wheel reducer oil 3-19 V/R
TYRES
Tightening the wheel nuts 3-16 C
Condition of wheels and tyres 3-10 C**
HYDRAULIC SYSTEM
Hydraulic return oil filter cartridge 3-20 R
Hydraulic oil level 3-12 C
Hydraulic oil 3-20 V/R
Hydraulic circuit strainer 3-20 N
Emergency pump 3-16 C
Turret motor brake reducer 3-21 V/R
ELECTRICITY
Battery charge 3-11 C
Batteries 3-11 Ch
Density of battery electrolyte 3-12 C
Battery electrolyte level 3-12 C
Tightening electric power cables 3-17 C
Replace the batteries 3-23
R
Battery boxes 3-13 V
State of manipulator boots 3-13 C
CHASSIS
Access platform slew ring 3-18 G
Tightening screws on the turret slew ring 3-18 C
Axles 3-15 G
LIFTING STRUCTURE
Tightness of the bolts on the turret rotation motor 3-21 C
SAFETY COMPONENTS
Arm position sensors 3-13 C**
Slope sensor 3-13 C**
Overload sensor 3-17 C**
LIFTING PLATFORM
General inspection 3-10 C C
Functional checks 3-10 C C
Lifting platform stickers 3-13 C**
Overload 3-22 C
Stopping distance 3-22 C
Fitting slings on the lifting platform
3-24/25
OPTION
SafeManSystem condition 3-14 C
* : Contact your dealer.
647536 (10/04/2017) 150 AETJ C / 170 AETJ L
