Manitou 150 AETJ C User Manual

2-19
on the basket console : on the base console :
- Beeper 33* sounds constantly. - LED 3* flashes regularly.
- LED 22* flashes in sets of 5 flashes - LED 4* flashes in sets of 5 flashes
every 2 seconds. every 2 seconds.
For your safety, the access platform is equipped with two sensors for the low arm position and two for telescope extension / retraction. If only one
sensor is activated in either of these functions, the display (see Ref. 7 on the next page) displays fault code “F02005”. At the same time :
on the basket console : on the base console :
- Beeper 33* remains silent. - LED 4* flashes in sets of 5 flashes
- LED 22* flashes in sets of 5 flashes every 2 seconds.
every 2 seconds.
If the fault continues to be displayed, immobilise the platform and make the necessary repairs.
Consult y
our dealer.
* : the above references are the same as those used in the description of these components in the following pages.
4
NB :
INCOHERENCE of OVERLOAD SENSORS, LOW ARM position
and TELESCOPE extension / retraction.
This memo is to inform you that the slope and overload LEDs may, in certain
situations, be activated intermittently and the beeper may sound constantly, for
reasons other than excessive slope position or overloaded basket.
For your safety, the access platform is equipped with two overload sensors. If only one
sensor is activated, the access platform is blocked, the display (see Ref. 7 on the following
pages) displays fault code “F02004”. At the same time :
647536 (10/04/2017) 150 AETJ C / 170 AETJ L
