Manitou 150 AETJ C User Manual

2-41
15 daNm
2 daNm
22 mm
PROCEDURE OF FREE WHEELING
The platform may only be towed a short distance and only by a
machine with significant braking performance, in order to hold it:
the two machines must be connected by a tow bar.
- To set the platform to free wheel, it must not be subject to any travelling stresses from
slopes. The wheels must be able to turn freely.
- If possible, raise the platform to free the drive wheels in order to facilitate the operation.
- Loosen bolt 1 (Fig. F) on each wheel 22 mm from the edge, up to the resistance point,
without forcing it (2 daNm) : see (Fig. G).
- The machine can be towed as a trailer.
Warning : do not loosen screws more than 22 mm ; risk of rupture
and major damage to the reducer.
If in doubt, contact your dealer.
REINSTALLATION
- Turn the wheel gently from left to right to reset the gear while retightening the screws
(1) (Fig. F). Pay attention to the torque when tightening (15 daNm).
F
G
1
LOCKING
UNLOCKING
647536 (10/04/2017) 150 AETJ C / 170 AETJ L
