Manitou MC 40 Powershift User Manual

3 - 22
D10/1
D10/2
2
1
D10 - CAB VENTILATION FILTER
CLEAN
- Remove the cover plate 1 (Fig. D10/1).
- Lift out cabin ventilation filter 2 (Fig. D10/2).
- Clean the filter with a compressed air jet.
- Check its condition and change if necessary (See chapter : FILTERS CARTRIDGES
AND BELTS in paragraph : 3 - MAINTENANCE).
- Put back the cover plate 1(Fig. D10/1).
NOTE : For air conditioned cabs, refer to the air conditioner operator's manual.
D11 - B
ATTERY ELECTROLYTE DENSITY
CHECK
The electrolyte density varies depending on the temperature concerned, but a minimum
of 1260 at 16°C must be maintained. In the shaded area (Fig. D11), the battery is in a
normal charge condition. Readings above this zone indicate that the battery needs to be
recharged.
The density should not vary more than 0.025 units between cells.
- Check the electrolyte density in each battery cell using a hydrometer.
- Do not carry out this check immediately after topping up with distilled water. Recharge
the battery for at least an hour before checking the battery electrolyte density.
Handling and servicing a battery can be dangerous, take the following precautions :
- Wear protective goggles.
- Keep the battery horizontal.
- Never smoke or work near a naked flame.
- Work in a well-ventilated area.
- In the event of electrolyte being spilled onto the skin or splashing in the eyes, rinse
thoroughly with cold water for 15 minutes and call a doctor.
D12 - FRONT AXLE DIFFERENTIAL OIL
DRAIN
Place the lift truck on level ground with the I.C. engine stopped and the differential oil
still warm.
Dispose the drain oil in an ecological manner.
- Place a container under drain plugs 1 (Fig. D12) and unscrew the plugs.
- Remove level plug 2 (Fig. D12) and filler plug 3 (Fig. D12) in order to ensure that the
oil is drained properly.
- Refit and tighten drain plugs 1 (Fig. D12) (Tightening torque 34 to 49 N.m).
- Fill up with oil (See chapter : LUBRICANTS AND FUEL in paragraph : 3 -
MAINTENANCE) by filler port 3 (Fig. D12).
- The level is correct when the oil level is flush with the edge of port 2 (Fig. D12).
- Check for any possible leaks at the drain plugs.
- Refit and tighten level plug 2 (Fig. D12) (Tightening torque 34 to 49 N.m) and filler plug
3 (Fig. D12) (Tightening torque 34 to 49 N.m).
D11
1.240
1.250
1.260
1.270
1.280
1.290
1.300
-10
14
-18
0
°C
°F
0
32
10
50
20
68
30
86
40
104
D12
1
1
1
3
2
