Manitou MSI 30 T User Manual

2-43
19 - ROOF LIGHT (OPTION)
20 - HEATING VENTS (OPTION)
21 - HEATER CONTROL (OPTION)
Allows the temperature inside the cab to be adjusted.
A - With the valve closed, the fan delivers fresh air.
B - With the valve opened completely, the fan delivers warm air.
The intermediate positions allow the temperature to be adjusted.
22 - DOORS LOCKS (OPTION)
Two keys are provided with the lift truck to enable the cabin to be locked.
23 - LEFT SIDE WINDSCREEN OPENING HANDLES (OPTION)
24 - LOCKING HANDLE FOR UPPER HALF DOOR (OPTION)
25 - RELEASING BUTTON FOR UPPER HALF DOOR (OPTION)
26 - STEERING WHEEL TILTING HANDLE (OPTION)
This handle enables the angle of the steering wheel to be adjusted.
- Turn handle 1 towards A to loosen and adjust steering wheel.
- Turn handle 1 towards B to lock steering wheel in the position required.
A
B
B
A
1
