4-7
2012.12 Tools - STACKY
TOOLS FOR THE STACKY 10 STACKER
Tool part
number
Q
Centre of
gravity of
load
A1 A2 A3 B B1 min B1 max C D E E1 E2 F Weight
Unit kg mm mm mm mm mm mm mm mm mm mm mm
mm mm kg
FA 1000 500 950 1025 - - 180 700 60 80 40 - - 730 105
FR 1000 600 1150 1185 35 560 200 320 90 - 70 - - 700 80
POT * 500 600 600 660 35 46 - - 160 - - - - 320 33
EPE 1000 350 700 735 35 Ø 60 - - 160 - - - - 320 33
PLF 1000 350 700 735 35 600 - - 275 - 90 - - 630 65
BEC 200 350 85 150 - 400 - - 250 - - - - 630 24
REB 200 300 600 645 45 - 130 570 180 8 40 - - 730 32
PLX 1000 450 935 935 35 608 - - 145 - 140 90 150 630 98
FUT 300 600 795 600 - 1057 350 650 245 - 240 631 92
* LE model only
