4 Models and Parts
Operating and Installation Instructions UL 21
No. Designation Qty.
1
Left side cover 1
2
Baffle plate 1
3
DIN 53085 A2 M5 x 10 serrated hex flange bolt 2
4
M4 A4 serrated flange nut 2
5
Closed moisture removal box 1
6
40–60 mm hose clamp 2 (for 10.10/10.20)
7
Sleeve 1 (for 10.10/10.20)
8
Intake pipe 1 (for 10.10/10.20)
9
DN 50 gland grommet 1 (for 6.10/10.10)
2 (for 6.20/10.20)
10
Exhaust air bracket 1
11
Air vent extension 1 (for 6.10/10.10)
2 (for 6.20/10.20)
12
Fan 2
13
Rear cover 1
14
M4 x 10 A2 pan head screw 7
15
Right side cover 1
16
DIN 933 M8x40 screw 4
17a DIN 7982 8 x 25 countersunk
bolt
(depending on unit model)
5
17b
M5 x 25 A2 countersunk bolt 5
18
Front cover 1
